Patang - Surveillance

Defense organizations that are looking to gain situational awareness for their respective areas need to deploy an efficient and robust Tethered Unmanned Aerial Vehicle (TUAV) as soon as possible. Our technical team at Dynauton Systems, after conducting deep research and analysis regarding the optimization of surveillance systems, successfully developed a portable device, PATANG. It is a versatile TUAV that can easily carry a vast array of customizable and quick-swappable payloads.


These UAVs are specifically designed for performing aerial tasks that demand long operational durations. PATANG UAVs are a perfect fit for HADR scenarios, day/night coverage, and executing the right actions in high-stress defence environments. PATANG is known for its efficient operation at high altitudes, which allows it to have a wide detection range while transmitting HD videos to the operator, thus leveraging the entire aerial reconnaissance process.



profeature0
Type

Tethered UAV

profeature1
Cable Length

100m

profeature2
MTOW

8 kg

profeature3
Operational Role

Surveillance

Key Specification

Copter Weight 8 kg
Cable Weight 2 kg
Cable Length 100 m
Max AGL 100m
UAV transportation case size 750mm x 700mm x 700 mm
Diameter 855 mm
Diameter (including propellers) 1310 mm
Height 455 mm(The copter is foldable for easy portability and storage)
Gimbal Angular Movement Pan: -180° to +180°, Tilt: 0 to 90°
EO 30x Optical Zoom, 10x Digital Zoom 1280x720p
IR 10xDigital Zoom, 640x480p
